Pro Surveillance Power Box DC12V 30A 360W 18 CH, CCTV POWER BOX
$119.99
1 in stock
NEW IN BOX
- 12 Volt DC 120V/240V switching power supply. Connect and power 18 devices
- CE recognized to meet safety requirements
- Fan-less transformer to reduce noise. Each output comes with its own fuse and LED indicator
- 30 Amps continuous current. 360 Watts total power output. 12V 2A per port, 30A total shared.
- Fuse Type : PTC (Resetable) Fuse Rating : 2.3Av
- Punch-out holes for allowing cable access are available on the following sides: Heavy duty solid construction for installation in any environment.Regulated and Filtered
Surge Protected
LED Indicator for each channel
110V AC Input
Total Output Current : 30A
Total Outputs :18
Fuse Type : PTC (Resetable)
General protection: each output has independent PTC fuse and LED indicator, when problem occurs, only affect the independent output, other outputs still working.
Circuit short protection: when short condition occurs, independent PTC fuse will open the circuit,when condition removed, PTC fuse will automatically back to close.
High voltage protection: when high voltage occurs, the surge protection will be hit through to protect the connected device.
Over Current protection: when over current occurs, the power supply will automatically switch to self-protection status, when condition removed, then switch back to normal.
Application : CCTV Camera, PTZ, IR illuminator, Video Processor, Access Control , etc.
Additional information
| Weight | 5.81 lbs |
|---|---|
| Dimensions | 10.00 × 10.00 × 3.50 in |
| Brand | |
| Type | |
| Power Source | |
| Voltage | |
| Model | |
| Connectivity | |
| Power |
